Grey Black Electricalsilicone Potting Compound For Electronics Waterproof Thermal Potting Silicone For Connector PCB Cable

Name: Grey Black Electricalsilicone Potting Compound For Electronics Waterproof Thermal Potting Silicone For Connector PCB Cable
Brand: Hanast
Price: 1 USD

Cheap Grey Black Electricalsilicone Potting Compound For Electronics Waterproof Thermal Potting Silicone For Connector PCB Cable for sale

Brand Name : Hanast

Model Number : HN-8806

Certification : ROHS

Place of Origin : Guangdong,China

MOQ : 1kg

Price : USD

Payment Terms : T/T, , D/A, D/P, Alipay

Delivery Time : 3-5 days

Packaging Details : 25kg/barrel

Name : Thermal conductivity potting glue

Operating Temperature Range : -55°C to 200°C

Package : 25kg/barrel

Regular Color : Grey,black,white

Chemical Resistance : Excellent

Mix Ratio : A：B = 1:1

Shelf Time : 6 months

Flame Retardant Grade : UL-94V0

Customized : Support

Usage : PCB,battery,power module,led driver

Contact Now

Grey Black Electricalsilicone Potting Compound For Electronics Waterproof Thermal Potting Silicone For Connector PCB Cable

Product description:

Silicone potting compound is an electronic encapsulation material primarily made of silicone rubber. It is used to protect electronic components and provides waterproofing, moisture resistance, insulation, and shock resistance. After curing, it forms an elastomer that remains stable over a wide temperature range and exhibits good thermal conductivity and electrical properties.

Grey Black Electricalsilicone Potting Compound For Electronics Waterproof Thermal Potting Silicone For Connector PCB Cable

Product application:

Application Areas

New Energy: Such as battery management systems and power modules for electric vehicles.

Electronics and Appliances: Such as LED lighting, power supplies, sensors, and industrial control equipment.

Military and Aerospace: Used to protect sensitive electronic components.

Medical: Such as component packaging in medical devices.

Grey Black Electricalsilicone Potting Compound For Electronics Waterproof Thermal Potting Silicone For Connector PCB Cable

Test Items	Test Standard	Units	Product test results
Test Items	Test Standard	Units	Part A	Part B
Before Curing	1	Appearance	By eyes	---	Grey, fluid	White, fluid
	2	Viscosity	GB/T10247- 2008	25ºC,mPa·S	4500~5000	4500~5000
	3	Density	GB/T 13354-92	25ºC,g/cm3	1.50±0.05	1.50±0.05
	4	Mixing Ratio (A : B)	1:1	Weight ratio	100	100
	4	Mixing Ratio (A : B)	1:1	Volume ratio	100	100
	5	Operating time	Measured	hr	0.3-0.4
	6	Curing condition	Measured	hr	4~12 (25ºC, initial cure)
	6	Curing condition	Measured	hr	0.20 (80ºC)
After Curing	7	Appearance	By eyes	---	Grey Elastomer
	8	Hardness	GB/T 531.1-2008	Shore A	50±5
	9	Thermal conductivity	GB/T10297-1998	w/m·k	≥0.76
	10	Expansivity	GB/T20673-2006	µm/(m,ºC)	210
	11	Moisture Absorption	GB/T 8810-2005	24h,25ºC,%	0.01~0.02
	12	Volume resistivity	GB/T 1692-92	(DC500V),Ω· cm	1.0×1016
	13	Dielectric intensity	GB/T 1693-2007	Kv/mm(25ºC)	18~25
	14	Temperature Resistance	Measured	ºC	-50~+250

- Storage and transportation:

This product is non-toxic non-dangerous goods, according to the general chemical handling, stored in a cool & dry place (room temperature).

- Shelf Life: 6 months, overdue please reinspect; If it meets the standard, it can still be used.

Grey Black Electricalsilicone Potting Compound For Electronics Waterproof Thermal Potting Silicone For Connector PCB Cable
